PP Demister Pad (FR-15)

PP Demister Pad
PP demister(also known as mist eliminator, demister pads). This is a kind of high efficiency separation devices, used throughout all kinds of process industries, to remove liquid droplets from gas and/or vapour streams.
Mechanism:
The principle of demister operation is based on having a large number of obstacles intercepting entrained droplets in a vapour flow. This large number of obstacles must provide minimum drop in pressure over the removal system.
The demister is employed where the liquid droplet size is below 10 microns. The pad is made up of knitted mesh of metallic or synthetic material. The vapour is made to pass through this mesh, causing the vapour to flow freely but the liquid droplets being entangled due to inertia.
The droplets stick to the mesh surface for a brief period of time. As more and more droplets collect, they coalesce into a larger droplet, gaining weight and eventually falling off due to gravity. The vapour thus separated is almost free of liquid.
Material:
Some of the commonly used materials are:
PTFE, polyethylene, polypropylene, nylon yarn, glass fiber and PVC
Diameter: 0.20-0.45mm
Model: 40-100 60-150, 140-400
Packing
Wooden box or According to the customers' requirement.
