3D Curvy Welded Wire Mesh Fencing

Specification:

Material: Q235 Low carbon steel wire

Wire Diameter: 4.0mm/5.0mm(Galvanized wire is 4.0mm and after PVC coated is 5.0mm), other diameter on request.

Mesh Size: 50mm X 200mm(other size on request)

Finished: Galvanized and PVC coated

Coating Colors: RAL 6005 Green, RAL 6020 Green, RAL 9010 White, RAL 9005 Black, RAL 7035 Grey, RAL7030 Grey, RAL 5011 Blue. (Other RAL colors on request)

Height X Lenght X Crimped:
0.63m X 2.00m X 2
0.83m X 2.00m X 2
1.03m X 2.00m X 2
1.23m X 2.00m X 2
1.43m X 2.00m X 2
1.63m X 2.50m X 3
1.83m X 2.50m X 3
2.03m X 2.50m X 4
2.23m X 2.50m X 4
2.43m X 2.50m X 4

Post: Fixed by clips, Connected by steel flat bar, Fix by 'ABS' sheet, Fix by invisible bolts, Fixed by double steel connectors.


Application: Fencing and protection for road, railway, airport, residence district, seaport, garden, feeding and husbandry

Product Feature Corrosion resistant, age resistant, sunshine proof, weather proof.

Corrosion Form Electric galvanized, Hot-dipped galvanized, PVC coated, Electric galvanized then PVC spraying, Electric galvanized then PVC coated.
