6 Inches Antiabrasive Slurry Pump

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Incoterm:: FOB, CFR, CIF, EXW

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Delivery Time:: 20 Days

Transportation:: Ocean, Land, Air

Port:: Tianjin, SHANGHAI, NINGBO

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shijiazhuang
Productivity:	300sets/month
Payment Type:	L/C,T/T,Western Union
Incoterm:	FOB,CFR,CIF,EXW
Certificate:	ISO
Transportation:	Ocean,Land,Air
Port:	Tianjin,SHANGHAI,NINGBO

Product Description

Mining Slurry Pump:
Mining slurry pump are suitable for metallurgy ,mine ,coal,electric power and building materials to transport slurry with strong corrosion and high concentration. The mining slurry pump can be also used by multistage in series.The mining slurry pump body has changeable anti-friction metal liner or rubber liner ,the impeller is made of anti-friction metal or rubber. Position of opening in the mining slurry pump can be spaced in 45° angle,
turn eight different angles for installation.
The mining slurry pump are suitable for transporation abrasive solid bearing slurry with maximum concentration of wt.45%(ash)and wt.60%(ore)

Slurry Pump Performance Table:

Type	Allowable Mating Max.Power(kw)	Clear Water Performance						Impeller
		Capacity Q		Head H (m)	Speed n (r/min)	Max EFF η(%)	NPSH) (m)	No of Vanes	Impel Dia(mm)
		(m3/h)	(L/S)
1.5/1B-BH	15	12.6-28.8	3.5-8	6-68	1200-3800	40	2-4	5	152
2/1.5B-BH	15	32.4-72	9-20	6-58	1200-3200	45	3.5-8	5	184
3/2C-BH	30	39.6-86.4	11-24	12-64	1300-2700	55	4-6	5	214
4/3C-BH	30	86.4-198	24-55	9-52	1000-2200	71	4-6	5	245
4/3D-BH	60
6/4D-BH	60	162-360	45-100	12-56	800-1550	65	5-8	5	365
6/4E-BH	120
6/4D-BH	60	180-396	50-110	7-61	600-1600	55	3-8	4	372
6/4E-BH	120
8/6E-BH	120	360-828	100-230	10-61	500-1140	72	2-9	5	510
8/6R-BH	300
8/6E-BH	120	360-828	100-230	7-52	400-1000	70	2.5-6	4	536
8/6R-BH	300	360-828	100-230	7-52	400-1000	70	2.5-6	4	536
10/8ST-BH	560	612-1368	170-380	11-61	400-850	71	4-10	5	686
12/10ST-BH	560	936-1980	260-550	7-68	300-800	82	6	5	762
14/12ST-BH	560	1260-2772	350-770	13-63	300-600	77	3-10	5	965
16/14ST-BH	560	1368-3060	380-850	11-63	250-550	79	4-10	5	1067
16/14TU-BH	1200
10/8E-BM	120	540-1440	150-400	14-60	600-1100	73	4-10	5	549

* Dimensionally Interchangeable:

Horizontal Abrasion & Corrosion Resistant Slurry Pump Structure:

slurry pump elastomer parts

slurry pump metal parts

packing seal

slurry pump expeller assembly

bearing assembly

Shipping:

1. Port : TIANJIN ,CHINA
2. By sea for batch goods.FCL or LCL.
3. Customers specifying freight forwarders or negotiable shipping methord.
4. Deliver Time:15-30 days for batch goods.

Payment terms:

1. Payment :T/T or L/C 50% deposits,50% balance before delivery.
2. MOQ:1 pcs
3. Warranty:According to your working condition information.
4. Packing : Complete Pump: 1pc per wooden case ;
( Proof water plastic cloth and export wooden case. Thickness about 9mm-15mm).
