PCB assemble, OEM services are welcome

Get Latest Price

Payment Type:: T/T, PayPal or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, PayPal or Western Union

Product Description

Materials: FR-4/HTG150-180 FR-4/CEM-1/CEM-3/aluminum

Layer: 1 to 20

Board thickness: 0.2 to 4.0mm

Board thickness tolerance: ±10%

Copper thickness: 17.5 to 175μm (0.5 to 5oz)

Minimum trace width: 0.15mm

Minimum space width: 0.15mm

Minimum drilling: Ø0.2mm

PTH copper thickness: 0.4 to 2mil (10 to 50μm)

Tolerance of etching: ±1mil (±25μm)

V-cut angle: 25, 30, 45 and 60°

Pearl strength of line: ≥ 6lb/in (≥ 107g/mm)

Impedance control and tolerance: 50Ω±10%

Twist and wrap: ≥ 0.5%

Solder mask: green, red, blue, white, black and yellow

Surface finish/plating: HASL/lead free HASL/OSP/goldplating/immersion gold/ENIG

Certification: RoSH Directive-compliant, ISO 9001, SGS andUL

File protal 99se/P-CAD/Autocad/Cam350

Quantity: prototype and low volume PCB assembly from 1 board to250 is for specialty but we can handle orders up to 1000

Type of assembly: SMT and thru-hole

Solder type: water soluble solder paste, leaded andlead-free

Components: passives down to 0201 size BGA and VFBGA lead lesschip Carries/CSP double-sided SMT assembly fine pitch to 08 milsBGA repair and re ball part removal and replacement-same dayservice

Bare board sizes:

Smallest: 0.25x0.25 inches
Largest: 20x20 inches

File formats bill of materials Gerber files pick-n-place file(XYRS)

Type of service: turn-key, partial turn-key or consignment

Component Packing: cut tape tube reels loose parts

Turn time: same day service to 15 day service

Testing: flying probe test X-ray inspection AOI test

PCB or PCB assembly files requests:

Gerber files of the bare PCB board
BOM (bill of material) for assembly
Testing guide and test fixtures if necessary
Programming files and programming tool if necessary
Schematic if necessary

Smallest: 0.25x0.25 inches

Largest: 20x20 inches

Gerber files of the bare PCB board

BOM (bill of material) for assembly

Testing guide and test fixtures if necessary

Programming files and programming tool if necessary

Schematic if necessary
