Heavy slurry pump

1.General description
NZJ(L) series slurry pumps are
designed as single-stage, single-suction centrifugal pumps. The pumps are
innovative in both hydraulic and structural
design.
2.Introduction
NZJ(L) Series slurry pumps are
classified into the horizontal type (NZJ type) and vertical type (NZJL type)
according to construction.The wet parts are made from high-chrome alloy with
high wear-resistance. They are of energy- saving, high efficiency, little
vibration, low noise, long service, lightweight, reliable operation and easy
maintenance.
NZJ(L) Series slurry pumps are suitable for handling abrasive
and corrosive slurries with maximum concentrations of wt.45% (ash) and wt.60%
(ore) such as the fine ore and tailings in mining, removing ash in power plant
and delivering coal tailings. The pumps can be operated in series according to
special requirements.
3.Model Explanation
200NZJ (L)-A60

N: Our company(Norman)
ZJ: Slurry pump
L: Vertical type
200:
Discharge size (mm)
A: Impeller number A:5, B:4, C:3,F:6, G:7, H:8
60:
Impeller Diameter(cm)
