Gypsum board manufacturing machines
- Payment Type:
- T/T, L/C
- Incoterm:
- FOB
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 120 Days
- Transportation:
- Ocean
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 2 to 30 million sq.m per year |
| Supply Ability: | 20 sets per year |
| Payment Type: | T/T,L/C |
| Incoterm: | FOB |
| Certificate: | ISO9001:2008 SGS |
| Transportation: | Ocean |
Gypsum board manufacturing machines
Annual capacity: 2 to 50 million square
meters
Guarantee:3 YEARS and forever after sales service.
Experience: 16 years manufacturing experience till 2015
Exported to more than 15 countries such as: Iran, Uzbekistan, Pakistan, Saudi Arabia, Egypt, Ethiopian, Tanzania etc.
1.The parameters
are as follows
Production specification
Common paper faced plasterboard
Fire proof paper faced plasterboard
Water resistance paper faced plasterboard
Annual capacity
2 million sqm one year to 30milliom one
year
Production process
Dosing section-forming section-cutting
section-edge trimming and stacking section
Final production verity
Thickness from 7mm-15mm
Length from 2400mm-3600mm
Width 1200mm-3600mm
Fuel
Coal., fuel oil, natural gas, or liquefied
petroleum gas(LPG)
Advantages
(1) The equipment structure is reasonable,
energy saving, high degree of automatic, producing cost is low, have
competitive advantage.
(2) Production(gypsum board) qualified rate
99%
(3)low cost for test machines, after
equipment is installed, you can go to produce. With 24 hours, the product
pass rate can up to 99%
2.Material
consumption
Construction gypsum powder, modified starch,
protective paper, foaming agent, water, white latex. Fiberglass and paper pulp
(adding selectively)
according to different raw materials and
kinds of products) Quantity of raw material required for producing per m2
gypsum board (referenced data) (thickness based of gypsum board: 9.5mm)
Gypsum powder(CaSO4·1/2H2O)
6.8kg/m2
Protective paper
0.48kg/m2
Modified starch
0.035kg/m2
Foaming agent
0.008kg/m2
White latex
0.005kg/m2
Fiberglass (used selectively )
0.025kg/m2
Electricity
0.3kwh/m2
Water
4.8kg/m2
Heavy oil
Heat consumption~3800kcal/m2
Natural gas
Heat consumption~3800kcal/m2
