Drywall production equipment with 16 years experience
- Payment Type:
- T/T, L/C
- Incoterm:
- FOB
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 120 Days
- Transportation:
- Ocean
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 2 to 30 million sq.m per year |
| Supply Ability: | 20 sets per year |
| Payment Type: | T/T,L/C |
| Incoterm: | FOB |
| Certificate: | ISO9001:2008 SGS |
| Transportation: | Ocean |
Drywall production equipment with 16 years experience
1.The parameters are as follows
Production specification
Common paper faced plasterboard
Fire proof paper faced plasterboard
Water resistance paper faced plasterboard
Annual capacity
2 million sqm one year to 30milliom one
year
Production process
Dosing section-forming section-cutting
section-edge trimming and stacking section
Final production verity
Thickness from 7mm-15mm
Length from 2400mm-3600mm
Width 1200mm-3600mm
Fuel
Coal., fuel oil, natural gas, or liquefied
petroleum gas(LPG)
Advantages
(1) The equipment structure is reasonable,
energy saving, high degree of automatic, producing cost is low, have
competitive advantage.
(2) Production(gypsum board) qualified rate
99%
(3)low cost for test machines, after
equipment is installed, you can go to produce. With 24 hours, the product
pass rate can up to 99%
2.Material
consumption
Construction gypsum powder, modified starch,
protective paper, foaming agent, water, white latex. Fiberglass and paper pulp
(adding selectively)
according to different raw materials and
kinds of products) Quantity of raw material required for producing per m2
gypsum board (referenced data) (thickness based of gypsum board: 9.5mm)
Gypsum powder(CaSO4·1/2H2O)
6.8kg/m2
Protective paper
0.48kg/m2
Modified starch
0.035kg/m2
Foaming agent
0.008kg/m2
White latex
0.005kg/m2
Fiberglass (used selectively )
0.025kg/m2
Electricity
0.3kwh/m2
Water
4.8kg/m2
Heavy oil
Heat consumption~3800kcal/m2
Natural gas
Heat consumption~3800kcal/m2
Maybe you have
the same questions as follows:
1.Why price is high?
A:Where do you think high?Which product make
you feel ours is high?In the current market,there is no cheap one than us
during the same level.If you want to say small workshop,indeed,their machine is
cheaper,but not on the same level.
2.How much is your cost?
A:Do you have a well known about our
product?If not,you can not judge fairly about our machines whether cheap or
expensive.You care about price because you want have profit.Know more about our
product and marketing strategies,or take a visit of our factory,you will know
well about price.
3.Why your price is cheap?
A:That is our selling points and product
strategies.First,we buy a large number of material,and reduce the
cost.Second,we have good faith management,no bad assests,the mnagement can be
maximized efficiency.And last,Our management idea is a cost-effective way,low
profits,low price.If you have sincere buying our machine,we can discuss price.
4.Do you have quality
assurance?
A:Definitely,we have.If we can not assure the
quality,can I sell to you?I seek to a long business cooperation,not only once.
We have passed ISO9001.
Our service:
(1)Turnkey solution inquiry
(2)One year for free maintainence
(3)One year for free for replacing machine
parts
(4)Workshop layout design
5.What should do if
happens quality problem?
A:No one wants problems.The reason caused by
delivery,we will analyse at once,if our problems,we take responsibility,pls don`t
worry,we will follow by the contract,solve problems immediately and provide
good service to you.
