safeguard Razor Barbed Wire Mesh( ISO9001:2008)

Specifications Razor Barbed Wire Mesh

1.material :Galvanized steel sheet,wire or stainless steel sheet,wire

2.Usage: frontier defence,prison.

  material : Galvanized steel sheet or wire  or stainless steel sheet or wire
Usage: frontier defence,prison

razor barbed wire
Outside Diameter	No. of Loops	Standard Length per Coil	Type	Notes
450mm	33	8M	CBT-65	Single coil
500mm	41	10M	CBT-65	Single coil
700mm	41	10M	CBT-65	Single coil
960mm	53	13M	CBT-65	Single coil
500mm	102	16M	BTO-10.15.22	Cross type
600mm	86	14M	BTO-10.15.22	Cross type
700mm	72	12M	BTO-10.15.22	Cross type
800mm	54	10M	BTO-10.15.22	Cross type
960mm	52	9M	BTO-10.15.22	Cross type

Reference Number	Blade Style	Thickness	Wire Dia	Barb Length	Barb Width	Barb spacing
BTO-12		0.5±0.05	2.5±0.1	12±1	13±1	26±1
BTO-18		0.5±0.05	2.5±0.1	18±1	15±1	33±1
BTO-22		0.5±0.05	2.5±0.1	22±1	15±1	34±1
CBT-65		0.6±0.05	2.5±0.1	65±2	21±1	100±1
