high speed barbed wire making machine

Specifications barbed wire making machine

Pulling cord speed:134rotation/min

Collection speed:30-255rotation/min

easy and safe to operate.

CS Type Barbed Wire Making Machine,barbed wire machinery

Model	Barbed space	Single Strand Wire Dia.	Barbed Wire Dia.
CS-A CS-B CS-C	3”, 4”, 5”,6”	1.6mm-2.8mm	1.6mm-2.5mm

     The CS-A Specification

No.	Unit	Items	Parameters
1	Electromotor	Type	Y100L2-4
2	Electromotor	KW	3
3	Main drive shaft speed	rotation/min	402
4	Spooling barbed wire speed	rotation/min	470
5	Pulling cord speed	rotation/min	134
6	Collection speed	rotation/min	30-255
7	Mainframe size	mm	1900×1300×980
8	Wire collection part size	mm	1300×500×500
