welded wire mesh panel fence

Get Latest Price

Delivery Time:: 20 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Hebei, China (Mainland)

Product Description

Specifications welded wire mesh(factory)

1.material:Low-carbon Iron wire

2.opening:1/4"-8"

3.wire dia:0.5-5.0mm

4.low price,high quality

Welded Wire Mesh

Materials : selected quality Low carbon steel wire , stainless steel wire,PVC wire.
It throughs the process of automation and sophisticated welding technique . The end product is level and flat , sturdy structure , and even strength throughout , the netting shows no wear and tear when cutting off a part or under a stress
Processing:
· Galvanized after welding
· Galvanized before welding
Packing: Each roll wrapped with water proof paper or plastic shrink packing.
Application: Welded wire mesh is used in industry and agriculture building , transportation and mining for all such purposes as poultry houses, egg baskets, runway enclosures, draining rack, fruit drying screen, fence.

Standard Welded Wire Mesh (in 30m length, Width of 0.5m-1.8m)
Mesh		Wire Gauge (BWG)
Inch	MM	Wire Gauge (BWG)
1/4" x 1/4"	6.4mm x 6.4mm	22,23,24
3/8" x 3/8"	10.6mm x 10.6mm	19,20,21,22
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21,22,23
5/8" x 5/8"	16mm x 16mm	18,19,20,21
3/4" x 3/4"	19.1mm x 19.1mm	16,17,18,19,20,21
1" x 1/2"	25.4mm x 12.7mm	16,17,18,19,20,21
1-1/2" x 1-1/2"	38mm x 38mm	14,15,16,17,18,19
1" x 2"	25.4mm x 50.8mm	14,15,16
2" x 2"	50.8mm x 50.8mm	12,13,14,15,16
1/4" x 1/4"	6.4mm x 6.4mm	12, 13, 14, 15, 16

Welded Fencing Mesh (in 30m Length, Width of 0.5m -1.8m)
Mesh		Wire Diameter
Inch	MM	Wire Diameter
2" x 3"	50mm x 75mm	2.0mm,2.5mm,1.65mm
3" x 3"	75mm x 75mm	2.67mm,2.41mm,2.11mm,1.83mm,1.65mm
2" x 4"	50mm x 100mm	2.11mm,2.5mm
4" x 4"	100mm x 100mm	2.0mm,2.5mm

PVC Coated Welded Mesh (in 30m Length, Width of 0.5m-1.2m)
Mesh		Wire Gauge (BWG)
Inch	MM	Wire Gauge (BWG)
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21
3/4" x 3/4"	19mm x 19mm	16,17,18,19,20,21
1" x 1"	25.4mm x 25.4mm	15,16,17,18,19,20
