SB-EPS/wool rock aluminum composite panel production line for simple house

SB-EPS/wool rock aluminum composite panel production line for simple house

Get Latest Price

Payment Type:: L/C, T/T

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Delivery Time:: 30 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Hebei, China (Mainland)
Supply Ability:	10 Set/Sets per Month
Payment Type:	L/C,T/T

Product Description

Specifications 1.CE and ISO are accapeted

2.good quality, fast delivery and best service

3.OEM is served

4.hydraulic automatic machine

Botou Shibo Machinery Manufacturing Co,.Ltd EPS and rock wool sandwich production line

1.Main parameters

Constituent parts	coiler, roll forming machine, composite mainframe, cutting parts, find product rack
Forming size:	4500030002800
Feeding width	1000mm/1200mm
Main motor power	32KW
Working speed	0-4.05m/min
Equipment weight	20T
Electrical system	PLC Taiwan Delta
Rolling thickness	0.3-0.8mm
Power source	AC380V/50-60HX
Decoiler	Bearing 5-7tons
Number of forming rollers	13rows
Thickness of chain	0.6 inches
Out diameter of shaft	70 mm
Middle plate	12mm
Big frame	300 channel steel
composite mainframe	Squar Steel tube 80*160Glue shaft: 150 19roots

2.Process: Decoiling—active feeding (put the coil strip into the first feeding roller)—roll forming —hydraulic cutting is controled by computer system—product to stand
