Silicone Rubber Insulated Cable

heat cable/tape

heat tracer cable/heat tracing

constant wattage heat tracer

self regualting heating cable



Silicone rubber Insulated cable has excellent physical strength and mechanical properties, and outstanding resistance to heat, ozone, moisture, and chemicals. It also resists hardening or cracking under severe weather conditions. Sanewcable silicone rubber cable is capable of continuous current rating at 180oC if there are no limits imposed by environmental conditions. They can meet temperature and voltage ratings up to 250°C, they have great environmental resistance properties and can be used at temperatures as low as -60°C. They are halogen-free and are especially suitable for installation in power stations. Sanewcable can be tailored to meet a variety of demands such as extreme high and low temperature requirements, flame resistance, flexibility, radiation resistance, strength and purity.



Approvals : CE , UL and RoHS



Applications: Sanewcable silicone rubber insulated cable is used extensively for robotic, petrochemical, industrial equipments and electronics ,aerospace and medical applications.









TYPES

Name

Main Usage

Specification (core)

Nominal Cross Section (mm2)



YGZ-450/750

Medium-sized silicon rubber insulated heat resistant , corrosion resistant, oil resistant flexible cable

Used among all kinds of movable electric equipment and tools with high temperature 2,3,4,5,7,

10,12,19,24,30,

37,44,48,54,61 0.75~2.5



YGVFZ-450/750

Medium-sized silicon rubber insulated NBR sheathed heat resistant , corrosion resistant,oil resistant flexible cable



YGC-600/1000

Heavy-duty silicon rubber insulated heat resistant , corrosion resistant, oil resistant flexible cable

Used among all kinds of movable electric equipment and tools with high temperature, able to bear larger enternal mechanical force 2,3,4,5 4~240
