heat preservation nails insulation nails

Specifications heat preservation nails insulation nails

high quality

reasonable price

                           Product Description         Insulation nails
Materials: Carbon steel, aluminum, tinplate and plastic.
Manufacturing methods: Automatic machining and injection.
Specifications: 3-10cm in length. The base plate is in diameter 3m or 4.2cm. Sizes can be custom made.
Feature:
*A-grade pp injection moulding plus superb steel nail
*the tensile capacity of sigle insulation nail )0.8KN
*value added of systematic heat transfer to single nail(0.004(m2. K)
*carried standard: JG 158-2004
Uses: The insulation nails can be widely used in floor heating industry, power plants, petrochemical external wall insulation engineering, architectural wall reinforcement, noise, the construction industry, dill diameter 8or10. Available in different lengths fitting to the thickness of insulation board. We can make all kinds plug according to buyers demanding.
Recommended assembly method
1. Operation at ambient temperatures between 15 and 25° C
2. Work surfaces should be clean and dry, free of dust, grease, oil and any other loose matter
3. Remove the protective release paper taking care not to touch the adhesive
4. Place the hanger in the required position and press the base against the surface to be insulated
5. Insulation can be impaled immediately and firmly locked with fastening clips but maximum strength of adherence is achieved after 24 hours    TYPE:
Pouring nails
Solid wall insulation nails with large-scale automated injection molding equipment, the quality of first-class. This product is widely used in wall insulation fixed-extruded plates, polystyrene plates, and all kinds of lightweight insulation products. Product Specifications: Customized according to user needs processing.
One external wall nail
Solid wall insulation nails with large-scale automated injection molding equipment, the quality of first-class. This product is widely used in wall insulation fixed-extruded plates, polystyrene plates, and all kinds of lightweight insulation products
Sub-body wall nails (plastic expansion bolt, nylon expansion bolt)
The so-called "nylon" is also a kind of plastic, but its tensile strength of the distortion degree and a relatively stronger than the plastic. It is useful in places where the cold weather construction, its tensile strength, prone to breaking.
Uses: It is useful in the polystyrene board (Shu-Lok board), extrusion plates and a variety of indoor and outdoor fixed insulation construction. Such as: Cold, constant temperature, wall plates and so on.
Twist-tie plastic hollow wall anchors expansion
Note the use of external wall insulation wall insulation anchoring nail nail anchoring system for external wall insulation layer of thermal insulation effect is particularly evident: A high compressive strength to prevent impact damage, low thermal conductivity can reduce the thickness of the wall structure; Dimensional stability is good, in the case of no deformation temperature, surface coating to prevent cracking, while providing a flat surface wall decorations, as well as grass-roots cement coating
Specification: 10*80, 10*90, 10*100, 10*110, 10*120, 10*140, 10*160, 10*180, 10*200, 10*220.

Base Size (mm)	Lock Panel (mm)	PIN DIAMETER(mm)	Nail Length (mm)
24×24	25	1.5	60
24×24	25	1.5	70
24×24	25	1.5	80
24×24	25	1.5	100
24×24	25	1.5	120
