Shuttleless Wire Mesh Weaving Machine Best Price!

  Shuttleless Wire Mesh Weaving machine    1.Application: used for industrial purpose, window doors and poultry’s guards, Sieves, filters and other purpose.       2.Character: single electromotor driving; be suitable for soft metal, stainless steel, flexible copper wire, galvanized wire, etc       (1).The machine adopts technique of shuttleless and straightaway weft leading, automatic warp feeding and winding. Shedding are small and surfaces of woven screens are smooth. There is not any bright spot, bright trace and other defects on fine screen. The machine can make light-grade in the standard of GB/T5330-2003.   (2). Lower center of the gravity, good stability, low noise and energy consumption, high efficiency.   (3). Rational design, simple construction, easy to operate and maintain.   3. Specifications for your reference:

Item	Weaving Width (mm)	Wire Diameter (mm)	Mesh Size (mm)	Weave Type	Weight (KG)	Outsize (mm)
APM-1300B	1300	0.04-0.25	40-400	Plain and Twill	2800	2600x2800x1200
APM-1600Q	1600	0.04-0.25	40-400	Plain and Twill	3200	2630x3200x1360
APM-1300B	1300	0.1-0.8 or 0.03-0.3	10-100 or 40-350	Plain and Twill	6155	2569x3535x1849
APM-1600Q	1600	0.15-0.8	10-40	Plain	2800	2569x3535x1849

      4.Picturesof maily wire mesh weaving machine :
