BOPP & BOPET FILM

Specifications BOPP & BOPET FILM

1.Excellent heat stability

2.High tensile strength

3.Good flatness of product appearance

  BOPP & BOPET FILM

Thickness	Length	Width	Core Size
12~50 µm		325mm~2500mm	3“ 6”
Note: Other specifications are customized. Regular roll lengths are 6000m,12000m, 18000m,24000m and 36000m.

          Typical Property of Product

Items	Unit	Typical Value	Test Method
Thickness	μm	12	DIN 53370
Tensile Strength(MD/TD)	MPa	230/245	ASTM D 882
Break Elongation(MD/TD)	%	130/110	ASTM D 882
Modulus of Elasticity(MD/TD)	MPa	4400/4600	ASTM D 882
Heat Shrinkage(MD/TD) 150°C,30min	%	1.5/-0.03	ASTM D 1204
Haze	%	2.8	ASTM D 1003
Gloss	-	170	ASTM D 2457
Wetting Tension	Dyne	58	ASTM D 2578
Note: MD: Machine Direction; TD: Transverse Direction. The above data can only be regarded as typical physical properties rather than guaranteed values, which can be adjusted at customer's request.
