12mic BOPET FILM

Specifications 12mic BOPET FILM

1. Perfect ink and metal adhesion

2.excellent surface tension stability

3.High mechanical property

12mic BOPET FILM Product Description GF01 is a bi-axially oriented PET film. It has been widely accepted for many flexible packaging applications such as color printing, vacuum metallization, multi-lamination etc. Main Properties • High mechanical property • Good dimensional stability • Excellent processing ability • Good ink and metal adhesion with high surface tension Specifications

Thickness	Width	Roll ID
12-125 µm	350-2200 mm	76.2mm(3”), 152.4mm(6”)

Typical Value

Property		Unit	Typical Value			Test Method
Thickness		µm	12	36	50	DIN 53370
Tensile Strength	MD	MPa	220	220	210	DIN 53455-6-5
	TD		250	250	250
Elongation at Break	MD	%	140	160	170	DIN 53455-6-5
	TD		100	100	100
Heat Shrinkage	MD	%	1.8	1.8	1.8	ASTM D1204 150°C,30min
	TD		0.2	0.2	0.2
Friction Coefficient		µs/µk	0.45/0.45	0.45/0.40	0.40/0.35	DIN 53375
Gloss(45o)		%	135	135	135	ASTM D 2457
Haze		%	2.5	2.5	3.0	ASTM D 1003
Surface Tension		Dyne/cm	38	38	38	ASTM D 2578
