12mic Gold Silver Coated PET Films used for Gravure

  12mic Gold Silver Coated PET Films used for Gravure  Application : It is mainly used as the compound materials of electronic shielding pouch, a small number of them are used for decoration materials. It is commonly processed with CPP, PE, and the finished product will be used to pack the electronic consumption material. Product specification Thickness:8mic,10mic,12mic,15mic,18mic,etc   Width:≤2100m   Features: a) Raw material: polyester film, metallized with aluminum b) Maximum width: 2450mm c) Thickness: usually is 12um,16um .17um,18um.Of course,it is adjustable to customer's requirements d) Uses: packaging, printing, laminating, and decorating     sheet date

Metallized PET film
Properties		Units	Typical Values	Test Methods
Thickness		μm	12	DIN53370
Tensile Strength	MD	MPa	218	DIN53455-6-5
	TD		231
Elongation at Break	MD	%	111	DIN53455-6-5
	TD		114
Coefficient of Friction	F/F-μs	-	0.48	DIN53375
	F/F-μk		0.48
Heat Shrinkage	MD	%	2.0	BMSTT11
	TD		0.8
Thickness of Aluminum Layer		Ω/	2.0	Resistance Tester
Optical Density		OD	2.0	MACBETH TD904
Adhesion of Aluminum Layer		%	100	3M Gummed Tape
Tolerace of Aluminum Layer		%	6	Resistance Tester
Gloss		%	132.6	ASTM D2457
Surface tension		Dyne/cm	60	ASTM D2578
