plastic coated dutch welded fence/Holland wire mesh fence/Euro fence

Specifications 1.Single strand of high-strength steel wire:Diameter:3.0 + /-0.05mm; Width:0.5-2.5m;wire dia:1.0-3.0mm

2.anti-corrosion age

plastic coated dutch welded fence/Holland wire mesh fence/Euro fence   1.Material: low carbon steel wire ,electric galvanized wire ,stainless steel wire.      Weaving and characteristics : the warp bended beforehand is welded with the weft with the surface treated by galvanizing , hot galvanizing ,PVC coating ,PVC plating and passivating .the product has such characteristic as beautiful appearance,   smooth mesh, firm welding, good beforehand bending property, steadiness, good anticorrosion and resistance to aging.    Processing: PVC coated after welding of steel wire. Electro galvanizing, hot-dip galvanizing or PVC coating can be done separately.      Uses: the products are widely used in Europe, North America and Middle East for protection and partition in such fields as railways, highways, bridges, airports, sports, sport ground, husbandry ,city construction ,resistance building and factories and the deep process of articles for everyday use.   2. Width:0.5-2.5m;wire dia.:1.0-3.0mm       Property: Good corrosion resistance, antiaging, nice appearance, easy and quick installation       Packaging:in pvc bags , or kraft paper, then put into each roll pallet ,or containers. usually, as our customers'requirements

Model MPW	Wire  diameter (mm) warp wire Xweft wire	Reference  sizes of  particles passed (µm)	Section  opening (%)	Approximate weights (kg/square meter mesh)	Mesh thickness (mm)	Approximate meshes/inch warp X weft
28	0.71X0.63	315	14.2	5.42	1.97	7.24X44
32	0.63X0.45	300	20.4	4.04	1.53	8.49X62
40	0.50X0.355	250	21.5	3.16	1.21	10.2X79
45	0.45X0.315	224	21.2	2.84	1.08	11.8X89
(48)	0.45X0.315	212	20.6	2.86	1.08	12.2X89
55	0.40X0.28	180	20.1	2.56	0.96	14.1X100
60	0.40X0.28	160	17.6	2.64	0.96	16.1X100
68	0.355X0.224	160	23.0	2.14	0.803	17.2X125
70	0.355X0.25	140	16.7	2.37	0.855	18.7X112

76	0.315X0.20	140	22.3	1.90	0.715	19.3X140
90	0.315X0.224	112	15.7	2.13	0.763	21.8X125
100	0.28X0.20	100	14.6	1.92	0.68	25.6X140
120	0.25X0.18	80	13.6	2.64	0.61	30.0X155
140	0.224X0.16	71	12.7	1.58	0.544	35.1X175

160	0.20X0.14	160	12.5	1.40	0.48	40.6X200
180	0.16X0.112	56	15.0	1.09	0.384	45.4X249
200	0.14X0.10	50	14.6	0.96	0.34	51.3X279
