1.Galvanzied welded wire mesh
2.PVC Coated welded wire mesh
3.Dutch welded wire
Galvanized/PVC Coated Welded Wire Mesh/panal Welded wire mesh include: 1.Galvanized welded wire mesh 2.PVC Coated welded wire mesh 3.Dutch welded wire mesh Welded wire mesh Description: Material: high quality low carbon steel wire, stainless steel wire.
Welding Characteristics: galvanized before or after welding.
Surface Treatment: electric galvanized, hot-dipped galvanized, pvc coating, plastic-soaked.
Using: Industry, Agriculture, Building, Transportation, Mine, Filed, Lawn, Cultivation, Fence Guard, Decorate, Machine protection and etc. Galvanized welded wire mesh:
Galvanized Welded Wire Mesh | ||||
Specification in British System | Packing | |||
Mesh(inch) | BWG | Mesh(mm) | Wire Dia. | |
1” x 2” | 14 | 25.4mm x 50.8mm | 2.10 | 390 |
1” x 2” | 15 | 25.4mm x 50.8mm | 1.82 | 360 |
1” x 2” | 16 | 25.4mm x 50.8mm | 1.65 | 320 |
1” x 2” | 17 | 25.4mm x 50.8mm | 1.47 | 310 |
1” x 1” | 14 | 25.4mm x 25.4mm | 2.10 | 400 |
1” x 1” | 15 | 25.4mm x 25.4mm | 1.82 | 370 |
1” x 1” | 16 | 25.4mm x 25.4mm | 1.65 | 330 |
1” x 1” | 17 | 25.4mm x 25.4mm | 1.47 | 320 |
1” x 1” | 18 | 25.4mm x 25.4mm | 1.24 | 280 |
PVC Coated welded wire mesh PVC Coated Welded Wire Mesh | |||
Wire Dia. | Mesh(inch) | W X L | Note: |
0.6mm/ 0.7mm | 3/4” x 3/4” | 3’ x 100’ |
1”-6”
|
0.8mm/ 1.1mm | 1/2” x 1/2” | 3’ x 100’ | |
1.6mm/ 2.1mm | 3” x 2” | 3’ x 100’ | |
1.9mm/ 2.5mm | 2” x 1” | 3’ x 100’ | |
1.9mm/ 2.5mm | 2” x 2” | 3’ x 100’ | |
1.9mm/ 2.5mm | 3” x 2” | 3’ x 100’ | |
2.0mm/ 2.6mm | 4” x 2” | 3’ x 100’ | |
Dutch welded wire mesh: Dutch Welded Wire Mesh | ||||
Mesh(inch) | Wire Dia(mm) | Length(m) | Width(m) | |
Before Coating | After Coating | |||
2” x 2” | 1.5-1.9 | 3.0-3.5 | 10-50 | 0.6-2.1 |
2” x 3” | 1.5-1.9 | 3.2-3.7 | 10-50 | 0.6-2.1 |
2” x 4” | 1.5-1.9 | 3.2-3.7 | 10-50 | 0.6-2.1 |
Company profile Hebei Yeson International Trading Co.,Ltd. is a specialized international business company that has been focusing on import and export business for six years.Thanks to its continuous business growth every year, the company has become one of the leading import and export companies domestically in China.
