Professional standard HDPE pipe for building water

Professional standard HDPE pipe for building water   Application Fields
Municipal engineering water supply system, building indoor water supply system, outdoor undergroundwater supply system and the residential area, plant areaunderground water supply system, old pipeline repair, water treatment engineering piping system, garden, irrigation and other fields of industrial pipes etc.
But it is important to note that FRPP pipe cannot be used for hot water pipe.

Product Features
1. Easy to corresponding welding and electric fusion welding to form a complete closed seepage control system. Along the groove installation, can reduce the groove excavation earthwork quantity and reduce the dosage of accessories.
2. Light weight and easy to install.
3. Strong abrasion resistance and excellent hydraulic resistance, pipeline can buried without outer protection. Can be applied to earthquake and soil subsidence in mining area, can also be used into laying in the bottom of river.
4. Resistance to chemical corrosion, internal and external and microbial corrosion resistance, corrosion resistance is strong and healthy. Suitable for conveying acidic and alkaline substances, conveyingwaste water, natural gas, gas and other substances.
5. Good environmental adaptability and frost resistance. Can be used for indoor and outdoor water supply pipe.
6. Long service life, have more than 50 years of almost service life.
7. Easily recycled use. Physical Properties

Properties		Typical Value
Specific Gravity, g/cm3(20°C)		0.941~0.965
Longitudinal Reversion, %(110°C)		≤3
Oxidation Induction Time, min(200°C)		≥20
Extension Rate at Break,%		≥350
Hydraulic Pressure Test (PE100)	20°C	No Failure
	80°C,165h, Hoop Stress is 5.5MPa	No Failure
	80°C,1000h,Hoop Stress is 5.0MPa	No Failure

PE100 Specifications
PN	0.6Mpa	0.8Mpa	1.0Mpa	1.25Mpa	1.6Mpa
SDR	SDR26	SDR21	SDR17	SDR13.6	SDR11
OD	Thickness	Thickness	Thickness	Thickness	Thickness
20					2.3
25					2.3
32					3.0
40				3.0	3.7
50				3.7	4.6
63			3.8	4.4	5.8
75			4.5	5.6	6.8
90		4.3	5.4	6.7	8.2
110	4.2	5.3	6.6	8.1	10.0
125	4.8	6.0	7.4	9.2	11.4
160	6.2	7.7	9.5	11.8	14.6
180	6.9	8.6	10.7	13.3	16.4
200	7.7	9.6	11.9	14.7	18.2
225	8.6	10.8	13.4	16.6	20.5
250	9.6	11.9	14.8	18.4	22.7
280	10.7	13.4	16.6	20.6	25.4
315	12.1	15.0	18.7	23.2	28.6
355	13.6	16.9	21.1	26.1
400	15.3	19.1	23.7	29.4
450	17.2	21.5	26.7	33.1
500	19.1	23.9	29.7	36.8
560	21.4	26.7	33.2	41.2
630	24.1	30.0	37.4
710	27.2	33.9	42.1
800	30.6	38.1	47.4

  Packaging & Shipping Packaging: Plastic bag or as your request
Delivery time : 20days for 20ft container. 30days for 40HQ  Company Information In our factory we have 100 workers, 15 years experience,  ISO, CE certificated, soon reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.   Our Service   FAQ Q1.How to get free samples ?
A: Send your address, your telphone number , post code ,and express account number to our mail box .and told us which model of samples you need .
Q2.Who pay for the express cost ?
A: We can support you free samples each model 1-3 pcs ,as to the express you pay firstly,after place order we will return the freight to you.
Q3.What is your packing?
A: Usually plastic bags,carton, can be packed as your require. Quick response                                                                Waiting your kindly enquiry
