Electric Welding Rod electrodes And Welding Electrode Distributor For aws e6013 e7018

    SHIJIAZHUANG SHUANGLU MACHINERYCO.,LTD.       Electric Welding Rod electrodes And Welding Electrode Distributor For aws e6013 e7018   Shuanglu company can supply AWS E6013 is a low-carbon steel electrode with a high titaniume coating and can be used on AC. or DC . It has excellent welding technological properties . The arc is stable . The spatter is small. The slag viscosity is moderate. It can be used freely . The slag is easy to clean . The welded seam is smooth and fine and easy to restrike the arc.   Application Suitable for welding sheet metal structure made of low-carbon steel , such as ships, vehicles, building, and general machinery.

Chemical Composition of Wire(%)

C	Mn	Si	S	P
≤0.12	0.3-0.6	≤0.35	≤0.035	≤0.040

Mechanical Properties of Deposited Metal

Test Item	σb(MPa)	σc(MPa)	δs(%)	Akv(°C)(J)
Guarantee Value	≥420	≥330	≥17	-

  Recommended Welding Current

Electrode Diameter(mm)	2.0	2.5	3.2	4.0	5.0
Current Range(A)	40-70	50-80	80-120	150-190	180-240
