Carbon Steel Welding Electrode E6013 AWS E6013
- Min. Order:
- 1 ton
- Min. Order:
- 1 ton
Your message must be between 20 to 2000 characters
Contact Now| Supply Ability: | 50 Ton/Tons per Day |
|---|---|
| Payment Type: | L/C,T/T |
SHIJIAZHUANG SHUANGLU MACHINERYCO.,LTD.
Carbon welding electrode e6013 and welding electrode e6013
Shuanglu company can supply AWS E6013 is a low-carbon steel electrode with a high titaniume coating and can be used on AC. or DC . It has excellent welding technological properties . The arc is stable . The spatter is small. The slag viscosity is moderate. It can be used freely . The slag is easy to clean . The welded seam is smooth and fine and easy to restrike the arc.
Application
Suitable for welding sheet metal structure made of low-carbon steel , such as ships, vehicles, building, and general machinery.
Chemical Composition of Wire(%)
| C | Mn | Si | S | P |
| ≤0.12 | 0.3-0.6 | ≤0.35 | ≤0.035 | ≤0.040 |
Mechanical Properties of Deposited Metal
| Test Item | σb(MPa) | σc(MPa) | δs(%) | Akv(°C)(J) |
| Guarantee Value | ≥420 | ≥330 | ≥17 | - |
Recommended Welding Current
| Electrode Diameter(mm) | 2.0 | 2.5 | 3.2 | 4.0 | 5.0 |
| Current Range(A) | 40-70 | 50-80 | 80-120 | 150-190 | 180-240 |
