low hydrogen welding electrode e7018/low price weld electrode rod aws e7018

      SHIJIAZHUANG SHUANGLU MACHINERYCO.,LTD.     Low hydrogen welding electrode e7018 /low price weld electrode rod aws e7018   Welding Electrodes E7018   Introduction AWS E7018 is a kind of carbon steel electrode with iron powder low-hydrogen potassium type coating. AC/DC. The deposition efficiency can be improved due to the iron powder in the coating. It has stable arc, fewer spatters, good slag detachability and excellent welding performance. The deposited metal has excellent mechanical properties. All-position welding.   Uses Used for welding carbon steel and low-alloy steel structures, such as 16Mn, etc.   Notes on Usage

1. The electrodes must be baked under 300~350°C for an hour before welding and used as soon as baking is completed. 2. The stains on the weldments, such as rust, oil stains, moisture, etc., must be cleared away before welding. 3. When welding, short arc must be used and stringer bead is suitable.

    Chemical Composition of Deposited Metal (%)

Chemical Composition	C	Mn	Si	S	P	Ni	Mo	Cr	V
Guarantee Value	≤0.12	≤1.60	≤0.75	≤0.035	≤0.040	≤0.30	≤0.30	≤0.20	≤0.08

  Mechanical Properties of Deposited Metal

Test Item	Rm(MPa)	ReL(Mpa)	A(%)	KV2(J)
Guarantee Value	≥490	≥400	≥22	≥27(-30°C)

  Diffusible Hydrogen Content in Deposited Metal:≤8.0ml/100g(Glycerine Hydrogen Test)   Reference Current(AC, DC+)

Electrode Diameter(mm)	φ2.5	φ3.2	φ4.0	φ5.0
Length(mm)	300	350	400	400
Welding Current (A)	60~100	80~140	110~210	160~230

X-ray Radiographic Inspection:ⅠDegree
