    SHIJIAZHUANG SHUANGLU MACHINERYCO.,LTD.     SUNLU Horizontal Extruder   SYT  Horizontal Extruder
SYT horizontal extruder, as the special auxiliary equipment for press-coating of the powder layer of the welding electrodes, can produce a variety of common acid/alkaline welding rods, and special high-performance welding electrodes.
Specifications and Parameters

No.	Name	SYT-100A	SYT-200A	SYT-250A
1	Max. Coating Pressure	100T	200T	250T
2	Max. Powder Pressure	73Mpa	81Mpa	88Mpa
3	Max. Hydraulic Pressure	20Mpa	24Mpa	24.5Mpa
4	Conveying Capacity of Powder	0-5L/Min	0-13L/Min	0-16L/Min
5	Die-head Type	45°	45°	45°
6	Dimensions of Powder Ball	Φ125*150mm	Φ172*150mm	Φ180*150mm
7	Height of Working Center	990mm	1050mm	1050mm
8	Fuel Tank Volume	600L	1050L	1150L
9	Dimensions of Powder Cylinder	Φ132*760mm	Φ180*850mm	Φ190*850mm
10	Power	11kw	30kw	37kw
11	Dimensions	3600*1250*1400mm	3800*1400*1480mm	4050*1500*1520mm
12	Weight	3.5T	5.3T	5.8T

    Product photo
