10mm Armacell JIOS Aerogel Silica Aerogel insulation

10mm Armacell JIOS Aerogel Silica Aerogel insulation

About Aerogel Blanket

Huatao Group is majored in the Aerogel thermal insulation blanket which is widely used in the Thermal insulation. The material of the aerogel is Silica.

Silica aerogel is a particularly good insulator to prevent conduction, which is the basic characteristic of non-metallic inorganic materials.

Pyrogel XTF Aerogel Insulation Blanket For High Temperature Specification

Thickness:3mm,6mm,10mm
Roll Length:36M or as request
Width:1500MM or as request
Use Temperature:-50~650 C
Dimensional Stability(GB/T8811):1%
Reshrinking Temperature(GB/T11835):800 C
Compressive Property(GB/T13480):@10%,20Kpa
                      @25%,150Kpa
Flame Rating(GB/T8624):A
Tensile strength(GB/T17911):1000KPa
Thermal conductivity(GB/T 10295):25C,0.020W/(M·K)
                     200C,0.028W/(M·K)
                             300C,0.035W/(M·K)
                     400C,0.044W/(M·K)
                     500C,0.069W/(M·K)
                     650C,0.095W/(M·K)

The advantages of aerogel insulation materials are

Compared with the traditional aerogel insulation material, the thickness of the insulation layer can be greatly reduced, the heat loss is reduced, and the energy saving effect is excellent.

The aerogel insulation material has good structural strength, high compressive strength, stable performance and long service life.

The aerogel insulation material has good waterproof effect and prevents pipeline corrosion to a maximum extent.

To reduce installation time and labor, it is easy to tailor material and installation according to complex shape, curvature and space constraints.

The amount of aerogel insulation material can reduce the amount of external protective layer and reduce the cost of transportation and storage.

The combination of aerogels and other traditional materials provides a more economical insulation scheme for the users.
