5mm FLEXIBLE Pyrogel HPS Aerogel Silica Aerogel insulation

5mm FLEXIBLE Pyrogel HPS Aerogel Silica Aerogel insulation

Why is Aerogel Material so low in thermal conductivity and adiabatic?

From the way of heat transfer, we can see that two heat transfer modes have been blocked in three forms of heat conduction. Conduction and convection are the two ways of heat transfer, and the aerogel Material is made up of most of the insulating air, and the micromeshed network prevents the flow of gas. The conduction and convection are well done. The thermal conductivity of the air is about 25 mW/m. K, while the thermal conductivity decreases to about 5 mW/ in the pores of 30 nanometers. M. K. Thus the effect of aerogel thermal insulation blanket is achieved.

Pyrogel XTF Aerogel Insulation Blanket For High Temperature Specification

Thickness:3mm,6mm,10mm
Roll Length:36M or as request
Width:1500MM or as request
Use Temperature:-50~650 C
Dimensional Stability(GB/T8811):1%
Reshrinking Temperature(GB/T11835):800 C
Compressive Property(GB/T13480):@10%,20Kpa
                      @25%,150Kpa
Flame Rating(GB/T8624):A
Tensile strength(GB/T17911):1000KPa
Thermal conductivity(GB/T 10295):25C,0.020W/(M·K)
                     200C,0.028W/(M·K)
                             300C,0.035W/(M·K)
                     400C,0.044W/(M·K)
                     500C,0.069W/(M·K)
                     650C,0.095W/(M·K)

The advantages of aerogel insulation materials are

Compared with the traditional aerogel insulation material, the thickness of the insulation layer can be greatly reduced, the heat loss is reduced, and the energy saving effect is excellent.

The aerogel insulation material has good structural strength, high compressive strength, stable performance and long service life.

The aerogel insulation material has good waterproof effect and prevents pipeline corrosion to a maximum extent.

To reduce installation time and labor, it is easy to tailor material and installation according to complex shape, curvature and space constraints.

The amount of aerogel insulation material can reduce the amount of external protective layer and reduce the cost of transportation and storage.

The combination of aerogels and other traditional materials provides a more economical insulation scheme for the users.
