Braid Oil Resistant Rubber hydraulic hose
- Payment Type:
- L/C, T/T, Western Union
- Incoterm:
- FOB, CFR, CIF
- Min. Order:
- 1500 Meter
- Min. Order:
- 1500 Meter
- Delivery Time:
- 20 Days
- Transportation:
- Ocean, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 60000M/Month |
| Supply Ability: | 60000M/Month |
| Payment Type: | L/C,T/T,Western Union |
| Incoterm: | FOB,CFR,CIF |
| Certificate: | ISO9001:2008 |
| Transportation: | Ocean,Air |
Tube: Oil resistant synthetic rubber.
Tube standard: GB/SAE/DIN.
Reinforcement: One or two, more high tensile steel wire braided.
Working temperature : -40℃~+100℃(oil), -30℃~+50℃(air), below+80℃(water).
Application: Mineral, Mine hydraulic support, oil field exploitation, suitable for engineering
|
TYPE
|
SIZE
|
SIZE
|
I.D
|
W.D
|
O.D
|
W.T
|
|
mm
|
inch
|
mm
|
mm
|
mm
|
kg/m
|
|
|
4SH-10
|
16
|
5/8
|
15.4
|
16.4
|
23.2
|
0.90
|
|
4SH-12
|
19
|
3/4
|
18.6
|
19.8
|
27.6
|
0.84
|
|
4SH-16
|
25
|
1
|
25.0
|
26.4
|
34.4
|
0.76
|
|
4SH-20
|
31.5
|
1-1/4
|
31.4
|
33.0
|
40.9
|
0.65
|
|
4SH-24
|
38
|
1-1/2
|
37.7
|
39.3
|
47.8
|
0.58
|
|
4SH-32
|
51
|
2
|
50.4
|
52.0
|
62.2
|
0.50
|
Structure:
The inner layer: oil resistant synthetic rubber
Reinforcement layer: 4 layers strong spiraled steel wire
The cover = it is made of black cloth, oil resistant, weather resistant and wear resistant synthetic rubber.
[Safety Factor]: 4:1
[Application]: for transporting petroleum based hydraulic fluids and water-based hydraulic fluids
[work temperature] -40℃-+100℃
Joint: SHF-withhold
Color: black, red, blue, yellow, etc...
Appplications: This section covers hose for use with petroleum base hydraulic fluids within a temperature range of -40C~+100C
Product features: This hose shall consist of an inner tube of resistant synthetic rubber ,Four spiral plies of steel wire wrapped in alternating direction and an oil and weather resistant synthetic rubber cover .
Packaging
Size:
20m, 40m, 50m or 100m for a roll
Weight:
according to sepcification
Packaging Details:
wrap it with woven bag or wooden box or as the customers' request
