Barbed Wire , fencing barbed wire , hot dipped razor barbed wire

  Product Description

Product Description

Barbed Wire , fencing barbed wire , hot dipped razor barbed wire Material: Galvanized steel sheet, stainless steel sheet, stainless steel wire.   Process and Features: Galvanized steel plate or stainless steel plate punched into certain forms then attached to the steel wire in sharp angle to form the blades. The products offer beautiful appearance, economic cost, good frightening result and easy installation. Sharp blades coming in the form of concertina by buckles bring very good result of frightening and stopping to the aggressive perimeter intruders. Razor wire is divided into spiral, straight line and crossed spiral types.    Razor blade specification:

Reference Number	Thickness mm	Wire Diameter	Blade Length	Blade Width	Blade Spacing
BTO-12	0.5±0.05	2.5mm±0.1	10mm±1	13mm±1	26mm±1
BTO-18	0.5±0.05	2.5mm±0.1	10mm±1	13mm±1	26mm±1
BTO-22	0.5±0.05	2.5mm±0.1	20mm±1	15mm±1	33mm±1
BTO-28	0.5±0.05	2.5mm±0.1	15mm±1	15mm±1	33mm±1
BTO-30	0.5±0.05	2.5mm±0.1	22mm±1	16mm±1	36mm±1
CBT-65	0.6±0.05	2.5mm±0.1	60mm±2	22mm±1	102mm±1

Barbed tape wire specification:

Diameter	No.of Loops	Standard Length per Coil	Type	Notes
450mm	33	7M-8M	CBT-65	Single coil
500mm	41	10M	CBT-65	Single coil
700mm	41	10M	CBT-65	Single coil
960mm	54	11M-15M	CBT-65	Single coil
500mm	102	15M-18M	BTO-12.18.22.28.30	Cross type
600mm	86	13M-16M	BTO-12.18.22.28.30	Cross type
700mm	72	12M-15M	BTO-12.18.22.28.30	Cross type
800mm	64	13M-15M	BTO-12.18.22.28.30	Cross type
960mm	52	12M-15M	BTO-12.18.22.28.30	Cross type
