ass heat reserve fireproof thermal and acoustical insulation fiberglsoundproof glass wool materials

Specifications thermal conductivity fireproof glass wool insulation

density:10-48kg/m3

thickenss:25-150mm

AS/NZS4859,CE

Heat insulation fireproof glass wool insulation       we can provide OEM service.         Product Description    Glass wool is made from fibreglass, which is layered and arranged to produce a similar texture to that of wool.  The way it's made is a bit like the way fairy floss is spun; molten liquid glass made from sand and recycled glass products is pulled through a superfine mesh by centrifugal force, and the tiny strands dry and cool on contact with air.  The individual fibres are held together with a binding agent, which helps to hold glass wool together and give it strength.  Once it's made, glass wool it is cut to size and packed in either rolls or panels (also called 'batts') for transport.     1. Standard Size:   insulation blanket for ceiling
Density:10-48kg/m3
Length:5m-30m
Width:1200mm,600mm
Thickness:25mm-185mm

Item	Products	Density kg/m3	Thickness	Size Length*width
1	Glass wool felt	10	50-150mm	10-30m*1200mm
2	Glass wool felt	12	50-150mm	10-30m*1200mm
3	Glass wool felt	14	40-150mm	10-30m*1200mm
4	Glass wool felt	16	25-150mm	10-30m*1200mm
5	Glass wool felt	18	25-150mm	10-30m*1200mm
6	Glass wool felt	20	25-150mm	10-30m*1200mm
7	Glass wool felt	22	25-150mm	10-30m*1200mm
8	Glass wool felt	24	25-150mm	10-20m*1200mm
9	Glass wool felt	32	25-150mm	10-20m*1200mm
10	Glass wool felt	38	15-150mm	10-20m*1200mm
11	Glass wool felt	48	10-120mm	10-20m*1200mm

Also can produce as request
2.Technical parameter Data   <div >

Number	Item	Unit	National Standard	Company Product	Remark
1	Density	kg/m3		10-48	GB483.3-85
2	Avearage Fiber diameter	μm	≤8.0	5.5	GB5480.4-85
3	Hygroscopicity	%	≥98	98.2	GB10299-88
4	Thermal Conductivity	w/m.k	≤0.042	0.033	GB10294-88
5	Noncombustibility	0	Noncombustible	Noncombustible (A)	GB5464-85
6	Sound Absorption Coefficient	0	0	1.03 product reverberation method 24kg/m3 2000HZ	GBJ47-83
7	Highest usage Temperature	°C	≤480	480	GB11835-89

  3: Application
Heat preservation for steel structure building ,
Heat insulation for wall and roof of house to save energy.
For indoor partition wall,Train compartment,
For cool-making and high buildings required to be fireproof,heat resistant and sound insulating.
4.Package

Standard package:Plastic package and weave bag,vacuumized package. Can print any information on weave bag.   4. Related Products       5 .PHOTO

Raw Materials List

Packing and Inspection

Loading Containers

Install Project      We welcome you visit our factory any time!
