Armaflex Insulation/ Rubber Foam Insulation For Hvac

      Product Description  NBR/PVC plastic rubber foam for air-conditioning  Apply in air-conditioning system
SGS, ISO, Certify
Flammability B1    Rubber foam specification   Main specification range: Length: 9m-30m Width: 1m,1.2m Thickness: 6mm,9mm-30mm   Technical parameter Data  Tenical parameter Data

Item		Unit	Specification	Standard
Density		Kg/m³	≤95	GB/T6343
Flammability	Oxygen index	%	≥32	GB/T2406
	SDR	——	≤75	GB/T8627
Conductivity factor Average temperature -20°C 0°C 40°C		W/(m.k)	≤0.031 ≤0.034 ≤0.036	GB/T10294
Watervapor permeability	Coefficient	g/(m.s.pa)	≤2.8*10-11	GB/T17146-1997
	Factor	——	≥7.0*10³
Water absorption ratio in vacuum		%	≤10	GB/T17794-2008
Dimension stability 105±3°C,7d		%	≤10	GB/T8811
Crack resistance		N/cm	≥2.5	GB/T10808
Compression resilience ratio Compression time 72h		%	≥70	GB/T6669-2001
Anti-ozone Ozone pressure 202mpa 200h		——	Not cracking	GB/T7762
Aging resistance 150h		——	Slightly crumpling, no cracks,	GB/T16259
Temperature		°C	-40°C——110°C	GB/T17794

     Distinctive advantages   • Closed structure can effectively prevent thermal conduction.   • Thermal conductivity :0.034W/m • k while 0   • High heat emission coefficient of surface, up to 9W/m2k   • Excellent anti-steam permeated ability; moisture resistance 10,000 (DIN 52615); "built-in"    steam-proof coating; the insulation board is insulating layer and moisture-proof coating as well.   • Excellent fireproofing; oxygen index is above 40.   • Easy for installation.   • No CFC, HFC, HCFC or other materials containing fluorine, also no formaldehyde, dust or fiber.       Delivery Information MOQ: 1X20"FT, 1X40"HQ Delivery Time: Within 7-15 days after received advance Payment: T/T, L/C, DP & DA and we can discuss.    Packaging & Shipping   Product picture show:           ,       Company Information     Our Company Mission: Help partners to achieve success. Cooperaion wih customers to create a win-win situation. We will guarantee the best quality and service let you more satisfied.        When you have free time, welcome to visit our factory any time.   For Further query,please contact on Skype: "supersale004" Whats App: "+86-15830677921"
