automatic roofing nail making machine

Specifications automatic roofing nail making machine

1.designed capacity(Pcs/min): 110-150

2.weight(kg): 2100

automatic roofing nail making machine:

Technical data	Z94-4A
Dia of nail max(mm)	4.0
Dia of nail min(mm)	2.38
Length of nail max(inch)	3''
Length of nail min(inch)	1.5''
Designed capacity(Pcs/min)	110-150
Motor power(kw)	4.2
Weight(kg)	2100
Dimension(mm)	2500×1500×1700

Advantage: High speed and low nosie. The speed of this machine is less than or equal to 800 pcs/min, the noise is below 76 db. The speed is 3 times of the Z94 nail making machine, the noise is 30% lower than common nail making machine.   Working Principle: A. this machine adopts autimatic wire releasing, which changed the condition of different length of nail caused                                      by the unsteady of wire releasing power; B. during production, this machine adopts high absorbtion strength, to separate the nail and waste angle, and absorb the waste angle into the storage bucket; C. this machine got the high temperature protection device at kinfe, mould, rear bearing parts. When the temperature is too high, nail making error is more than 0.5 mm or the sliding part is lack of oil, the machine would stop automatically. It reduced the machencical accident; D. this machine is easy to produce various of nails by changing moulds, and is very suitable for D type nail producing.    Factory address:   Our factory is located in Shijiazhuang city of Hebei Province, China.   It is 280km south of Beijing.    There is CRH Train from Beijing to our city. It takes about 1 hour and 20 mins.
