Supplier of Iron Wire Drawing Machine

Specifications iron wire drawing machine

Maximum inlet diameter:6.5mm

Minimum outlet diameter:2.0mm

production:245m/min

iron wire drawing machine   1. Wire drawing machine is made up of main reducer gearbox,mould case,guiding wheel frame and electrical inventer control system. 2. wire drawing machine is mainly used in drawing metal wires, such as,steel wire,aluminum wire,copper . 3. the steel wire is widely used in construction.     Parameter

Model	550
Unit Motor(kw)	18.5/22
Strength tensile kg/MM2)	MPA≥110
Max. Inlet(mm)	6.5
Mini. Outlet(mm)	2.0
Drawing path	1-7
Pot diameter.(mm)	560
Capacity m/min	245
Total compress	78-88.5%
Equal compress	13%
Inverter	INVT
Unit weight(kg)	1600
Overall size(mm)	6900*1700*2100
