safety barrier fence plastic

  Product Description Materials             Quality hot strip steel Strip Steel Materials For Guardrail System:Q235B of China standard:

Standard Table
ISO	Germany	U.K.	French	U.S.A.	Japan	China
E235B	S235JR S235JRG1 S235JRG2	S235JR S235JRG1 S235JRG2	S235JR S235JRG1 S235JRG2	Cr.D A36	SS400 SM400A SN400	Q235B

    Chemical composition of carbon construction steel:Q235B of China standard:

C	Mn	Si	S	P
0.12%~0.20%	0.30%~0.67%	≤0.30%	≤0.045%	≤0.045%

     Processing  Steel Stamping for Beam Guardrail       post processing     Hot-Dip Galvanizing     Spray/ Impregnation Processing     Use of highway guardrails Highway guardrails are considered as passive protectors with a view to ensure the safety of the  pedestrians by the wayside and the vehicles. Highway guardrails are designed in pursuance to  the principle of keeping the vehicle inside the road in a secure way and at the same time minimizing  the loss of life and property in case of an accident.  Advantages of highway guardrails  It makes the road apparent.
 It prevents the pedestrians and the animals from entering the road.
 It ensures the safety of the drivers and the passengers by hindering the vehicles going off the road.   Size

specification	materials	thickness	length	wave width	wave hight	Protective finish	Standard
4128mm*311*83(85)	Q235(Q235JR)or Q345(Q355JR) or Q255JR	2.75mm	4128mm	311mm	83(85)mm	hot dipped galvanization zinc or plastic sprayed  coating weight:550—1220 g/m2	China EU USA AS/NZS
		3mm	4128mm	311mm	83(85)mm
		4mm	4128mm	311mm	83(85)mm
4320mm*311*83	Q235(Q235JR)or Q345(Q355JR) or Q255JR5	2.75mm	4320mm	311mm	83(85)mm
		3mm	4320mm	311mm	83(85)mm
		4mm	4320mm	311mm	83(85)mm
The specification according to your request
