drawing wire machine manufacturer

Specifications water tank wire drawing machine

drived by gears,

are capable of drawing rod wires of high-,

medium-,low-carbon

                                           water tank wire drawing machine   Usage:water tank wire drawing machine  is used to draw low, medium and high carbon iron wire, copper wire, aluminum wire.   technical parameter.

The diameter of drum(mm)	350
The numbers of drawing mold	11
Max input diameter(mm)	2.5-2.8
Min output diameter(mm)	1.2-1.4
The strength of input wire(N/mm2)	≤750
Over rall compression rate(%)	-14.2
Drawing speed(mm)	160-350
Overall dimension(mm)	2400×1400×1200
Motor power(kw)	YCT250-22/37
Weight(kg)	-4000

  Feature: 1.Charging system applied sectional coupling that obtain proper bearing of the axis.Reducer, wet box and charging box are on the same base for easy installation and lifting.  2.The surface painting is of high grade and both internal and external of electric-control cabinet applies plastic-spraying process.   3.It is divided into common control and variablefrequency control. Electric parts are all Chinese or international famous brands.
