Steel wire fire directly annealing furnace

Get Latest Price

Delivery Time:: 35 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Hebei, China (Mainland)

Product Description

Specifications annealing furnace of glassworks

Stove body

Belt speed: 50-500mm/min;

Steel wire fire directly annealing furnace 1. Whole length: 33.5 m; Entrance platform length: 2 m; Pre-heating area length: 4.5 m; Heating area length: 9 m; Slow cooling area length: 13.5 m; Cold area: 4.5 m; Belt with: 1.8 m; Furnace hight: 0.35 m; 2. Belt speed: 50-500mm/min; Belt Material: 1Cr13 stainless steel; Temperature: ≤680°C; Loading ability: ≤90Kg/; 3. Heating element using 0cr25AI5 material; spiral resistance wire, star type connection. 4. 6 channel independent temperature control, the accuracy is ±1°C. 5. Speed slowing equipment: XWED-95-3481-2.2KW, 1 set; 6. Hot air circulation type: 6 heat-resistant stainless steel liner, 6 hot air circulating fans (WGB-2.2D-550); 12 groups of heater. 7. Equipped with heat recovery device. 8. Installed power: 360 kw
