nail machine made in China

Specifications nail machinery can make nails from 10mm to 260mm

                                                              nail machinery 1,Feature This machine can make wire nails and steel nails.nail length is from 10mm to 260mm.     2.Process flow Steel wire --- wire drawing --- nail making --- nail polishing --- finished nail.                                                 nail production line   3.,Feature   1 .Both of the scrap iron wire and the new steel rod can be used to make nails by the automatic nail making machine .
2 .The automatic nail making machine can feed the materials automatically.
3 .The automatic nail making machine has the features of high speed, low noise, less impact and good continuity.   4.machine specifications,

Type(Unit)	1C	2C	3C	4C	5C	6C
Max length of nail (mm)	20	50	75	100	100-150	150-210
Max diameter of nail(mm)	1.2	2.5	3.2	4.0	5.0	7.0
Nail making speed(pcs/min)	450	300	280	250	250	180
Motor power(kw)	1.5	2.2	3	3	5.5	11
Weight(kg)	900	1350	1600	1900	2500	5500
Overall dimension(mm)	1350×950×1000	1650×1150×1100	1990×1200×1250	2280×1420×1330	2300×1450×1500	3510×1940×2015

    5.machine picture nail molds factory
