Z94C nail making machine with best price

Specifications 1.automatic nail making machine

2.high efficiency and capacity

3.low power and noise

                                        Nail Making Machine   Feature: (1)    The machine has attractive appearance, rational structure and high efficiency. It’s also very   durable in use, easy to maintenance with adequate durability. (2)    All the main components are made of quality steel, such as shaft, cams and gear. (3)   Use control handle at the inlet place in order to control incoming line at any time during operating. (4)   A friction gear is installed between crankshaft and flywheel. It plays a protective role of safety when the machine breaks down or overloaded. (5)    The machine makes use of full automatic production procedure. Once start, it could make nails continuously.                     Specification:

Technical	Z94-1C	Z94-2C	Z94-3C	Z94-4C	Z94-5C
Dia of nail max	1.6mm	2.8mm	3.1mm	4.5mm	5mm
Dia of nail min	0.9mm	1.2mm	1.8mm	2.8mm	3mm
Length of nail max	25mm	50mm	75mm	100mm	125mm
Length of nail min	9mm	16mm	30mm	50mm	80mm
Motor power	1.5kw	2.2kw	3kw	4kw	5kw
Weight (approx)	1200kg	1450kg	1800kg	2000kg	2000kg
Overall dimensions	1500x1300x1200	1700x1300x1400	2000x1400x1400	2200x1600x1650	2200X1600X1650
Production capability	550unit/min	350unit/min	350unit/min	260unit/min	260unit/min

   Nail Making Machine Nail polishing machine Technical parameter

Model	Lv-400	Lv-1000
Capacity	400Kg	1000Kg
Motor power	2.2kw	7.5kw
Overall size	1640*900*1000mm	2000*1500*1400mm

   Finished Nails     welcome to visit our factory   Ms dreamy Skype: Dreamsong5 phone number: 008615932212928
