QG 500 High Speed Paper Core Cutting Machine

Specifications Automatic Paper Core Cutting Machine

Round knife for cutting, equipped with the cylinder for auto cutting and unloading.

  Automatic Paper Core Cutting Machine     Usage: Used for cutting paper cores.   Feature:

1. It adopts circular blade cutting with cylinder auto knife feeding and auto unloading.

2. Cylinder movement is controlled by the valve and equipped with precise aluminium mould to ensure efficiency and product quality.

    Reference:   Paper Core Cutter Main Specification and Equipment Parameter

Tube Length	60-1500mm	Tube Diameter	50-100mm
Blade Quantity	14groups	Cutting Speed	20 branch tubes/min
Cutting Way	paper tube rotate,blade axes without rotate	Loading/unloading Way	manual
Fixation Way	Auto chuck	Operator	1
Down Blade Way	Pneumatic	Power Input	380V 3phase 4Wire
Cutting Thickness	2-18mm

Control System

PLC Controller	Delta	Man-machine Interface	text
Edition of Program	JS-Q2.0	Driving Components	CHNT
Signal Components	Omron	Pneumatic Components	Sanzheng

Size (mm)

Mainframe(L*W*H)	2600*700* 1200	Total Weight	1000kg
Power of Mainframe	1.5KW*6	Rotate Speed of Main-spindle	400r/min
