1600A Raw Paper Slitting Machine

Get Latest Price

Delivery Time:: 20 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Hebei, China (Mainland)

Product Description

Specifications apply to slitting ad rewinding siclone paper and raw paper

easy to operate and durable for use

low investment

high efficiency

1600A Slitting Machine Usage: Apply to slitting and rewinding raw paper. Specification:

Dividing &cutting speed	200m/min	Quantity of operators	1-2
Dividing & cutting capacity	60-600g/m2	Main machine power	1.5kw
Min. dividing & cutting width	40mm	Max. dividing & cutting diameter	650mm
Original paper max. width	1600mm	Cutters quantity	25 pairs
Original paper max. diameter	1200mm	Main machine spec. (mm)	220022001600
Paper feeding method	Lifting jack	Speed regulation	Electromagnetic Speed regulation
Paper reeling method	Pneumatic expansion internal retraction	Power supply	Four
Double-blade cutting, upper-dish type cutting disc, Inferior fovea cutter		The upper and lower blades can be adjusted within 20-1600mm for random width
Both edges of paper strip after cutting is smooth and clean cut without any burrs		All operations are integrated on the control panel of convenient operation
Paper roll is coiled firmly with clean-cut edges		High production capacity, output of each machine can supply pare for three paper tube reeling machines simultaneously.
Steel plate structure of the complete machine, favorable appearance		Controlled by double magnetic-particle brake with Uniform tension force
Low noise, stable operation
