FT EPC Paper and Film Slitting Machine

Specifications used to slit and rewind kinds of paper products and film products

equipped with atomaitc alignment device

megnetic power clutc

FT Automatic EPC Slitting Machine   Usage: Professional product used for slitting paper products, OPP film, PE, PVC, etc.   Features: 1.using electric eye to rectify deflection. 2.using double magnetic powder clutch to control the rewinding tension 3.using arithmometer to count automatically 4.using linear bearing defection rack, mini moment, high balance set of guide roll 5. high speed of cutting, little noise, stability for operation. 6.tension controlling system can be equipped according to the customers’demands.   Reference:

operation width	800-1800mm
Max unwinding diameter	800mm
core ID	50-76.2mm
max rewinding diameter	600mm
Min slitting width	12mm
Mechanical speed	0-120m/min

  unwinding part   rewinding part   circular blade   Ms. Sophie, tel: 86-311-85965533, skype: xuefei8648
