Automatic Paper Slitting and Rewinding Machine

Specifications used to slit and rewind paper products and films

double magnetic powdre clutches

auto counter

high efficiency, low investment

FT Automatic EPC Paper Slitting Rewinding Machine   Usage: Professional product used for slitting paper products, OPP film, PE, PVC, etc.   Features: 1.using electric eye to rectify deflection. 2.using double magnetic powder clutch to control the rewinding tension 3.using arithmometer to count automatically 4.using linear bearing defection rack, mini moment, high balance set of guide roll 5. high speed of cutting, little noise, stability for operation. 6.tension controlling system can be equipped according to the customers’demands.   Reference:

operation width	800-1800mm
Max unwinding diameter	800mm
core ID	50-76.2mm
max rewinding diameter	600mm
Min slitting width	12mm
Mechanical speed	0-120m/min

  unwinding    auto alignment device   Ms. Sophie, tel: 86-311-85965533, skype: xuefei8648
