Automatic Thermal paper roll cutting machine manufacture

Specification:

This machine is used for slitting and rewinding all kinds of thermal paper, including fax paper, cash register paper, ATM paper, ECG paper, medical record paper, POS paper, self-adhesive trade marks, non-woven cloth, films etc.

1.Thermal paper slitter rewinder adopts Siemens PLC control system and touch screen, all the parameters are displayed on the monitor, and it will automatic work.

2.The main motor adopts Siemens inverter motor, and frequency inverter control.

3.It adopts automatic lift-up loading system, it controlled by a separated motor from Taiwan.

4.All transmission rollers have been dynamic\static balance treated.

5.It adopts red line marking system, printing red line at the end of paper rolls.

6.It adopts round blades to slit, it equipped with automatic wasting     materials edge trimming system.

7.It adopts auto tucker, adjust the paper material loose or tight easily.

8.Rewinding adopts automatic tension control controller to keep constant tension.

9.It adopts auto meter counter, when it reach the setup length, the machine stop and alarm automatically.

10.It can avoid of overlap problem after paper reels are finished.

11.It equipped with emergency switch.

Max. Unwinding Width.

900mm

Max. Unwinding Dia.

1000mm

Max. Rewinding Dia..

160mm

Min. Slitting Width.

30mm

Machine max. speed

110m/min

Main power

2.95kw

Unwinding shaft

3”(76mm)air expanding shaft

Rewinding shaft

0.5” , 1” or as your request

Weight

1500kg

Dimension

2000x1700x1500mm
