Adhesive Stationery Bopp Tape Slitting Machine

Specifications Bopp Tape Slitting Machine

Unwind diameter: 800mm---1000mm

Rewind diameter: 120---500mm

Bopp Tape Slitting Machine         1.Use 4-axis automatic batch-exchanging and consecutive winding. ..     2.Stepless speed regulation of frequency conversion and configured with the three parted counters,stable and accurate stopping.     3.Releaseing tension use pneumatic brake control,winding tension use double-control,and equiped with a clutch and independent     4.The dividing knife use industrical knife,suitable for film adhesive tape slitting...     5.Airshaft for unwiding6.All button and swiftch use germanyschineider         Technical parameters:

valid width		1000mm/1300mm/1600mm
Max. unwinding diameter		600mm
slitting width		12-1280mm
I.D of paper core		76.2mm
rewinding I.D	four shafts rewind	76.2-150mm
	two shafts rewind	76.2-300mm
blade		0.2*22*60mm
machine speed		0-180M/min
main motor		5HP
