Semi-automatic Adhesive Stationery Bopp Tape Slitting Machine

Features

1. Add sound insulation cover, Can reduce the noise 60%, Improve the working environment

2. Individual Control the sound insulation cove, by two-liter hydro cylinder smoothly lifting.

3 Centralized control panel: All operation controls. For this machine are centralized in a control panel.

4 Three- step length setting: this length setting provides extremely smooth rewinding operation to gives accurate rewinding length.

5 Automatic shaft change: once the rewinding operation is accomplished, the machine will automatically perform shaft changes for convenient and efficient operations.

6 Crowned stretch Roll: The stretch roll is specially designed to eliminates tape wrinkling during extension and feed.

7 Pneumatic brake: Brings the machine to an immediate haft for accurate positioning and labeling.

valid width

1000mm/1300mm/1600mm

Max. unwinding diameter

600mm

slitting width

12-1280mm

I.D of paper core

76.2mm

rewinding I.D

four shafts rewind

76.2-150mm

two shafts rewind

   76.2-300mm

blade

   0.2*22*60mm

machine speed

   0-180M/min

main motor

5HP
