double wire fence/welded wire fence

Specifications double wire fence/welded wire fence

1,galvanized and pvc coated

2,CE certification and ISO9001-2001

3,10 year warraty

4,

double wire fence/welded wire fence        Material:
Using high quality Iron Rod as raw material, the welded panel, after galvanization, Powders Primer, and Powders top coating; it can resist the corrosive and ultraviolet radiation very strongly. The thickness of powder coating is 100-120 microns usually. The choose wire diameters are 6MM*2+5MM*1. 8MM*2+6MM*1. It obtains high strong powers to resist the construction.

Post:
This System usually choose Square Post (50*50mm, 60*60mm), Rectangular Post (80*60*2. 5mm, 120*60*3mm) With the high strength and so on. With plastic caps or Roofing rainhat. The finished surface usually is Galvanized and Powder coating, or alternatively.

Fastenings:
The Panels and posts are jointed together with bolts or rivets, using the steel flat bar, or special steel clamps, all nuts are self-locking. This also can be designed as the special clients requests.       Description:

Double Wire Fence
HeightxWidth Panel(mm)	Mesh Size (mm)	Wire Diameter			Post Height  (mm)
		Wire Dia (mm)	Wire Dia (mm)	Wire Dia (mm)
630X2500	50X200	8X2 + 6	6X2 + 5	6X2 + 4	1100
830X2500	50X200	8X2 + 6	6X2 + 5	6X2 + 4	1300
1030X2500	50X200	8X2 + 6	6X2 + 5	6X2 + 4	1500
1230X2500	50X200	8X2 + 6	6X2 + 5	6X2 + 4	1700
1430X2500	50X200	8X2 + 6	6X2 + 5	6X2 + 4	1900
1630X2500	50X200	8X2 + 6	6X2 + 5	6X2 + 4	2100
1830X2500	50X200	8X2 + 6	6X2 + 5	6X2 + 4	2400
2030X2500	50X200	8X2 + 6	6X2 + 5	6X2 + 4	2600
2230X2500	50X200	8X2 + 6	6X2 + 5	6X2 + 4	2800
2430X2500	50X200	8X2 + 6	6X2 + 5	6X2 + 4	3000
