QYM_popular welded mesh fence Discount!!

QYM-Welded Mesh Fence It is an economical version of the panel system, constructed from a welded mesh panel with longitudinal profiles that forms a rigid fence. The fence panel is welded with high quality low carbon steel wire, surface treated by electrostatic polyester powder spray coating over galvanized materials. Then connect the fence panel with post  by suitable clips. Due to its simple structure, easy installation and nice appearance, more and more customers  regard this product as the preferred common protective fence.

Panel-Type A

Mesh	Wire Thickness	Surface Treatment	Panel Width	Folds NOS.	Height
50x200mm or 55x200mm	4.50mm or 5.00mm	Galvanized and Electrostatic  polyester coatedor PVC coated	2.50m	2	830mm
				2	1030mm
				2	1230mm
				2	1430mm
				3	1630mm
				3	1830mm
				4	2030mm
				4	2230mm
				4	2430mm

  Panel-Type B

Mesh	Wire Thickness	Surface Treatment	Panel Width	Folds NOS.	Height
50x200mm and 50x100mm in folds Or 55x200mm and 55x100mm in folds	4.50mm or 5.00mm	Galvanized and Electrostatic  polyester coated or PVC coated	2.50m	2	1030mm
				2	1230mm
				3	1530mm
				3	1730mm
				4	2030mm

  Variations
In addition to the standard posts many variations are available
to accommodate site requirements:
• alternative sections
• wall fixing plates, cranked posts or base plates
• cranked or straight extensions for barbed or razor wire
• cranked panels   Fitttings
The fittings could be plastic or metal materials
