0.6 / 1kv EPR insulated PCP sheathed marine power cable, ZA type

Marine Power Cable

9.1 0.6 / 1kv EPR insulated PCP sheathed marine power cable, ZA type

Application: This product is applied to power transmission for kinds of marin transportation and offshore oil platforms, etc.
Standard: GB9331-2008

Type, Name and Application
Type
Name
Application
ZA-CEF
EPR insulated PCP sheathed marine power cable
For laying in fixed installation for offshore constructions
ZA-CEF80
EPR insulated PCP inner sheathed copper wire braid armoured marine power cable
ZA-CEF90
EPR insulated PCP inner sheathed steel wire braid armoured marine power cable
ZA-CEF82
EPR insulated PCP inner sheathed copper wire braid armoured PVC outer sheathed marine power cable
ZA-CEF92
EPR insulated PCP inner sheathed steel wire braid armoured PVC outer sheathed marine power cable
ZA-CEH
EPR insulated CSP sheathed marine power cable
ZA-CEH80
EPR insulated CSP inner sheathed copper wire braid armoured marine power cable
ZA-CEH90
EPR insulated CSP inner sheathed steel wire braid armoured marine power cable
ZA-CEH82
EPR insulated CSP inner sheathed copper wire braid armoured PVC outer sheathed marine power cable
ZA-CEH92
EPR insulated CSP inner sheathed steel wire braid armoured PVC outer sheathed marine power cable
ZA-CEFR
EPR insulated PCP sheathed marine power soft cable
ZA-CEHR
EPR insulated CSP sheathed marine power cable
ZA-CEV
EPR insulated PVC sheathed marine power cable
ZA-CEV80
EPR insulated PVC inner sheathed copper wire braid armoured marine power cable
ZA-CEV90
EPR insulated PVC inner sheathed steel wire braid armoured marine power cable
ZA-CEV82
EPR insulated PVC inner sheathed copper wire braid armoured PVC sheathed marine power cable
ZA-CEV92
EPR insulated PVC inner sheathed steel wire braid armoured PVC sheathed marine power cable
Specification:
Type ZA type
Cores
Nominal cross section (mm²)
CEF, CEF80, CEF90, CEF82
CEF92, CEH, CEH80, CEH90
CEH82, CEH92, CEFR, CEHR
CEV, CEV80, CEV82, CEV90, CEV92
1
1-300
2
1-120
3
1-185
4-37
1-2.5
