Low pinhole rate aluminized polyester film for Scintillators
-
$380.00≥30 Square Meter
- Min. Order:
- 30 Square Meter
- Min. Order:
- 30 Square Meter
- Transportation:
- Ocean, Land, Air, Express, Others
- Port:
- Tianjin, Shanghai, Qingdao
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | china |
|---|---|
| Productivity: | 500ton per month |
| Supply Ability: | 0.5 ton per month |
| Payment Type: | T/T,Paypal,Money Gram,Western Union |
| Incoterm: | FOB,CFR,CIF,FCA,CPT |
| Certificate: | SGS , ROSH , ISO |
| HS Code: | 3920620000 |
| Transportation: | Ocean,Land,Air,Express,Others |
| Port: | Tianjin,Shanghai,Qingdao |
Low pinhole rate aluminized polyester film for Scintillators
Low pinhole aluminized polyester film use extremely thin polyester film as base film and evapolated on both sides with aluminum
metal.it is especially used for alpha and beta particle radiation detectors as a light-tight radiation window.
It's extreme thinness precludes the absence of pinholes, and a light-tight radiation window is usually constructed with two closely
laid layers of the film thus achieving light tightness by virtue of the mis-alignment of the pinholes
The aluminized polyester film is supplied on rolls and It should be handled in a clean environment with care to avoid wrinkling and abrasion.
It may be cemented to support frames by using a variety of commercial adhesives including acrylics, silicones and epoxies. It may
be cleaned by rinsing with methanol or isopropyl alcohol or by gentle wiping with clean cotton soaked in alcohol.
It also can be used as the reflector sheet for scintillators.
Technical data sheet:
|
|
Al thickness A/B |
Ω/ □ |
≤1.0 A/B |
0.25～0.9Ω |
|
3u both sides |
Thick aluminum coated on PET substrate; 600A to 1200A; conductive; opaque Aluminum coating on both sides, thickened aluminum layer on both sides.for reflective use in the field of electronic components, security checks, detection rays; a-rays, Y-rays, beta-rays, X-rays |
|||
3u double side metallized polyester film application:
We have been in plastic film line for more than 19 years and we have much experience in plastic film of all
different application.
our main products are all kind of function film . main 4 seirers
a. hologram projection film
1. 45 degree hologram projection film
b.PET function film
1.PET color film 2. PET milky white film ,3white pet film 4. black PET film 5.Matte PET film 5.coated PET film
6.UV coating PET film etc
C. Metallized film
Alox PET film, metallized pet film,cu metallized PET film,double sided aluminized polyester film for radiation detectors etc
d electrical insulation film
PI film ,perforated polyimide film etc
flourine film etc
