75 Micron Transparent PET Release Liner film
-
$4.50≥500 Kilogram
- Min. Order:
- 500 Kilogram
- Min. Order:
- 500 Kilogram
- Transportation:
- Ocean, Land, Air
- Port:
- SHANGHAI, TIANJIN, NINGBO
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 1000ton/Month |
| Supply Ability: | 1000ton |
| Payment Type: | L/C,T/T,Paypal,Money Gram,Western Union |
| Incoterm: | FOB,CFR,CIF,FCA,CPT,CIP,DDU,DDP |
| Certificate: | SGS |
| HS Code: | 3920620000 |
| Transportation: | Ocean,Land,Air |
| Port: | SHANGHAI,TIANJIN,NINGBO |
75 Micron Transparent PET Release Liner film
Silicone Coated PET Film Description
Pet Releasing Film is made of Polyester film , and the product surface is coated with 0.2-0.6um Silicone for release .Film surface smooth , uniform coating, no wrinkles, no tears, no particles, no bubbles,no pinholes and other defects.The product has the advantages of excellent physical and mechanical properties, small thickness tolerance, high transparency, low thermal shrinkage and good flexibility.
Silicone Coated Polyester Film Application:
Pet Releasing Liner Film has been widely used in packaging, printing, screen printing, pad printing, nameplate, membrane switch, flexible circuits, insulation products, circuit boards, and laser anti-counterfeit, laminating, electronics, sealing material with film, reflective material, waterproof material, medicine (plaster) paper, toilet paper, adhesive products, die cutting, stamping processing, and other areas of the industry
Pet Release Film Specification date
1)Item: printing colored PET release film
2)Thickness: Usual: 36, 50, 75, 100, 125u . etc
3)Width: 22-1250mm
4)Length: 100-3000m (made as order)
5)Color: blue,red ,siliver ,gold
6)Printing: no (logo, word and picture can be printed as order)
7)Adhesion: low adhesion, medium adhesion, high adhesion, and super high adhesion
8)Adhesive strength: 50~300g/25mm
Technical date sheet
|
Spec |
||||||||
|
Thickness |
Length |
Width |
Core size |
|||||
|
10~50 µm |
|
325mm~2500mm |
3", 6" |
|||||
|
*) Other specifications on request. The typical lengths of reel roll equal to 12 µm film roll lengths are 6000m, 12000m, 18000m,24000m and 36000m. |
||||||||
|
The film is processed by three layer co-extrusion. Low heat shrinkage. High combination with multiple resin. High tensile strength. One side corona treatment is available. Stable quality. |
||||||||
|
Physical Property |
||||||||
|
Properties |
Unit |
Typical Value |
Scope |
Method |
||||
|
Thickness |
TD |
µm |
tolerance±4% |
12±0.2 |
DIN 53370 |
|||
|
Tensile Strength |
MD |
N/mm2 |
>200 |
100~235 |
ASTM D882 |
|||
|
TD |
N/mm2 |
>220 |
245~280 |
ASTM D882 |
||||
|
Elongation |
MD |
% |
>100 |
130~160 |
ASTM D882 |
|||
|
TD |
% |
>100 |
105~125 |
ASTM D882 |
||||
|
E Module |
MD |
N/mm2 |
>4000 |
4000~4300 |
ASTM D882 |
|||
|
TD |
N/mm2 |
>4200 |
4400~4800 |
ASTM D882 |
||||
|
Haze |
TD |
% |
2.5~3.0 |
2.5~3.0 |
ASTM D1003 |
|||
|
Heat Shrinkage |
MD |
% |
<1.55 |
1.3~1.5 |
BMSTT11 |
|||
|
TD |
% |
<-0.1 |
-0.1~-0.25 |
BMSTT11 |
||||
|
Wetting tension |
TD |
mN/m |
>54 |
58 |
ASTM D2578 |
|||
|
|
||||||||
Product show:
Our company is establised in 2004. we have much experience in plastic film.Our main products including 1.Metallized Film (VMPET,VMBOPP,VMPE ect) 2.Color PETfilm (PET Milky White Film , PET White Film , PET Black film ect ) 3.Coated PET Film 4.3D Pepper Ghost Foil ect . These products are widely applied to the packaging and printing of the industries including electronical products, food, commodities, medicine, labels, gifts etc.If you need anything, please feel free to contact me.
