Hot Sale Expanded Plate Mesh Machine

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Incoterm:: FOB, CFR, CIF

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Delivery Time:: 30 Days

Transportation:: Ocean, Land

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Hebei,China
Productivity:	5 sets per Month
Supply Ability:	5 sets per Month
Payment Type:	L/C,T/T,Western Union
Incoterm:	FOB,CFR,CIF
Certificate:	CE, ISO 9001
Transportation:	Ocean,Land

Product Description

Expanded Plate Mesh Machine

Cut thickness ≤ 6mm, wide tolerance greatly 2000mm, material intensity cold-rolled stencil plate of 450N/mm2 wash the network hangar, wash and cut the specification test and obtain actually according to the razor blade of the net board form TB5-20: If when TB and TL change, wash and cut strength change: When TB, TL increase, wash and cut strength reduce; When TB, TL reduce, wash and cut strength increase. Damage the part in order to make the machine overload, the name tonnage of this machine is 25T, TB, TL, reduce, wash, cut strength exceed name tonnage can reduce material prove degree and width solve.

This machine can be protected for the building, haberdashery and hardware, doors and windows, machine and the electronics industry manufactured goods wash and make various specification stencil plate networks.

This machine sends the material original reason host computer to transmit directly through gear wheel, ratchet wheel, cam, it is reliable that movements are accurate.

Send the material organization to wash to cut the number of times begin from 0, can all be cut off the arbitrary range.

expanded plate mesh machine

Type	60.3T	16T	25T	63T	125T
Punching sheet thickness	≤1.0mm	≤1.3mm	≤1.5mm	≤3mm	≤6mm
Punching sheet width	≤600mm	≤1000mm	≤1250mm	≤2000mm	≤2000mm
Times of Sliding	250r/min	150r/min	150r/min	70r/min	45r/min
Material distance	0.1-0.3mm	0-10mm	0-12mm	0-3mm	3.5-7.0mm
Sliding Distance	30mm	30mm	40mm	60mm	80mm
Cut the stencil plate continuously per hour	1.6m-13m	2.7m-5.4m	3m-6m	2.1m-12.6m	4.2m-8.4m
Power	2.2 kw	3 kw	4 kw	11 kw	22 kw
Outside Dimension	1090x710x1450	1740x1400x1870	1740x1400x1870	3560x3300x2280	5940x3270x1925
Complete machine weight	1.2T	2.4T	3T	11T	12.5T
Opening mesh	≤25mm	≤50mm	≤150mm	≤200mm	≤200mm

Flattening machine

Flattening machine special related to Expanded metal machine, after stencil plate mesh grind by flat mesh machine flat, have esthetic appearances, level smoothly, the advantage of high added value etc.

Currently the machine is applied to processing expanded metal with a maximum sheet thickness of 5.0 mm and a length 2100 mm

Technical Data	Type A		Type B
Roller width	2100mm	2100mm	1500mm
Diameter / Roller	720mm	540mm	550mm
Flat mesh thickness	5mm	4mm	4mm
Weight	22T	12T	6.5T
Motor Power	30kw	18.5kw	15kw
Outside Size	2.2mx3.0mx2.0m	2.2mx3.0mx1.5m	1.6mx2.8mx1.5m
